Double acting pneumatic cylinder with a 32-320 mm bore and 25-1000 mm stroke. It requires an operating pressure between 0.1 – 1.0 mpa. Self-lubricating, magnetic, adjustable damping, and has an end rod thread of M10×1.25. Wide range of mounting accessories available. The cylinder has an aluminum housing and comes with a NBR sealing, it is capable of operating within a temperature range of 20 to 80°C.
Pros
• It is double acting, allowing for full control of the rod.
• The grooved body allows for quick and easy sensor mounting
• The rod is self lubricating, meaning no lubricators are required in the air system. It will require little maintenance and have a long service life.
• It comes with the ability to adjust the damping, or cushioning, of the end of the rod stroke This way you can achieve perfect damping for every load situation.
Cons
• Not able to be operated in freezing environments
